6x2 HDMI Matrix
The 6x2 HDMI Matrix supports the feature of PIP, ARC, 4K and 3D, which can switch or splitter the six HD input sources to the two HD Displays. It also can do the audio extract by the Optical port or HP port. ARC feature can let you return your TV audio to
product infomation
- Item Name：
- Factory：Hiyou
- Origin：China
- Time Left：299d 21h(0000-00-00 00:00:00)
- FEATURES:
- Six HDMI Inputs switch or split to two HD Displays.
- HDMI supports Full HD,3D and 4Kx2K video
- Any input HD Source can do audio extract by the SPDIF or 3.5mm Headphone audio output port.
- HDMI to achieve the synchronization of audio signal separation.
- Support 2.0/ 5.1/ ADV three kinds of audio mode options
- Supports ARC ,TV audio will return and out by the Optical Port; （only the OUT A port supports ARC function）。
- Supports HDMI audio separation, can output by optical and 3.5mm Headphone at the same time
- Support SPDIF digital audio format: Dolby digital (AC3), DTS and LPCM2.0
- Support PIP function: have one main picture and five small pictures, it can do switch of input sources by press button or remote.
- LED indication: when source or sink is working, LED related will go bright.
- Support IR Remote Control and Push Button at device control.
- Led Status Light allows the user to know the working status easily.
- Power-off memory
- No loss of quality
- Need DC5V/2A power supply
- HDMI resolution ..........4KX2K/3D/1080p/1080i/720p/576p/576i/480p/480i
- Support HDMI audio format...........DTS-HD/Dolby-trueHD/LPCM/DTS/Dolby-AC3/DSD
- Digital Audio Output Supported Audio Format.........LPCM2.0/Dolby AC3/ DTS
- Digital Audio Output Sampling Rate........32KHz, 44.1KHz, 48KHz,88.2KHz, 96KHz, 176.4KHz, 192KHz
- Max transmission bandwidth.......................... 300MHz
- Max baud rate..............................9.0Gbps
- Input/Output TMDS signal ....................... 0.5~1.5Volts p-p
- Input/Output DDC signal ....................... 5Volts p-p (TTL)
- Input cable distance...... ....... ≤10m(1080P)/5M(4K) AWG26 HDMI standard cable
- Output cable distance........... ≤15m(1080P)/5M(4K) AWG26 HDMI standard cable
- Max working current............................700mA
- Power adapter format........Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/2A
- Operating Temperature range.........................-0 to +40℃
- Storage Temperature range....................... -20 to +60℃
- Operating Humidity range.................5 to 85%RH (No Condensation)
- Storage Humidity range..................5 to 95%RH (No Condensation)
- Dimension (L x W x H) ........................205x74x26 (mm)
- Weight........................................440g
FEATURES:
- Six HDMI Inputs switch or split to two HD Displays.
- HDMI supports Full HD,3D and 4Kx2K video
- Any input HD Source can do audio extract by the SPDIF or 3.5mm Headphone audio output port.
- HDMI to achieve the synchronization of audio signal separation.
- Support 2.0/ 5.1/ ADV three kinds of audio mode options
- Supports ARC ,TV audio will return and out by the Optical Port; （only the OUT A port supports ARC function）。
- Supports HDMI audio separation, can output by optical and 3.5mm Headphone at the same time
- Support SPDIF digital audio format: Dolby digital (AC3), DTS and LPCM2.0
- Support PIP function: have one main picture and five small pictures, it can do switch of input sources by press button or remote.
- LED indication: when source or sink is working, LED related will go bright.
- Support IR Remote Control and Push Button at device control.
- Led Status Light allows the user to know the working status easily.
- Power-off memory
- No loss of quality
- Need DC5V/2A power supply
- HDMI resolution ..........4KX2K/3D/1080p/1080i/720p/576p/576i/480p/480i
- Support HDMI audio format...........DTS-HD/Dolby-trueHD/LPCM/DTS/Dolby-AC3/DSD
- Digital Audio Output Supported Audio Format.........LPCM2.0/Dolby AC3/ DTS
- Digital Audio Output Sampling Rate........32KHz, 44.1KHz, 48KHz,88.2KHz, 96KHz, 176.4KHz, 192KHz
- Max transmission bandwidth.......................... 300MHz
- Max baud rate..............................9.0Gbps
- Input/Output TMDS signal ....................... 0.5~1.5Volts p-p
- Input/Output DDC signal ....................... 5Volts p-p (TTL)
- Input cable distance...... ....... ≤10m(1080P)/5M(4K) AWG26 HDMI standard cable
- Output cable distance........... ≤15m(1080P)/5M(4K) AWG26 HDMI standard cable
- Max working current............................700mA
- Power adapter format........Input: AC (50HZ, 60HZ) 100V-240V; Output: DC5V/2A
- Operating Temperature range.........................-0 to +40℃
- Storage Temperature range....................... -20 to +60℃
- Operating Humidity range.................5 to 85%RH (No Condensation)
- Storage Humidity range..................5 to 95%RH (No Condensation)
- Dimension (L x W x H) ........................205x74x26 (mm)
- Weight........................................440g
