Digital to Analog Converter
This product is a 4-Ports SPDIF switcher, also is a digital to analog converter. You can switch any one of the four digital audio signals to the one SPDIF/Toslink audio output. At the same time, it can convert the LPCM digital audio into analog L/R audio
product infomation
- Item Name：
- Factory：Hiyou
- Origin：China
- Time Left：299d 21h(0000-00-00 00:00:00)
- Feature：
- 4-Ports SPDIF (2×Toslink and 2×Coaxial) digital audio input, switch to 1-Port SPDIF/Toslink output
- and one L/R analog audio output and one headphone output
- Uses 192KHZ/24bit DAC
- Support digital audio formats: Dolby AC3, DTS, THX, HDCD, LPCM for SPDIF output
- Support LPCM digital audio converted to analog audio output
- Automatic identification input digital audio signal format, when non-LPCM input, analog output mute
- Input status indication. When no audio or error data input, the input port indicator starts to flash
- A key switch, easy operation
- Headphone amplifier output, can drive the general 3.5mm earphone
- High tone quality, low noise
- Power-off memory
- DC5V/1A power adapter
SPECIFICATIONS: ADSW0006M1
- Analog Audio Output Support audio format ........................ PCM/LPCM
- DAC sample frequency range.......................... 32～192 KHz
- DAC Bit rate range.................................16～24 Bit
- Digital input level................................0.1~1Volts p-p
- L/R output level(1kHz@0dB)........................................1V RMS
- Headphone output power (1kHz@0dB RL=32)......................30mW
- SNR @ 0dB(CCIR/ARM)................................90dB
- Distortion......................................0.1%
- Frequency response...............................20Hz~20KHz
- Max working current ...................................100mA
- Power adapter format Input ........................ AC 100V～240V 50HZ/60Hz, DC5V/1A
- Operating Temperature range ............................-10 to +55℃
- Storage Temperature range...........................-20 to +60℃
- Operating Humidity range .......................10 to 90%RH (No Condensation)
- Storage Humidity range........................5 to 95%RH (No Condensation)
- Case Dimension (L x W x H) ...........................85x62x21 (mm)
- Weight ..........................................130g
Feature：
SPECIFICATIONS: ADSW0006M1
- 4-Ports SPDIF (2×Toslink and 2×Coaxial) digital audio input, switch to 1-Port SPDIF/Toslink output
- and one L/R analog audio output and one headphone output
- Uses 192KHZ/24bit DAC
- Support digital audio formats: Dolby AC3, DTS, THX, HDCD, LPCM for SPDIF output
- Support LPCM digital audio converted to analog audio output
- Automatic identification input digital audio signal format, when non-LPCM input, analog output mute
- Input status indication. When no audio or error data input, the input port indicator starts to flash
- A key switch, easy operation
- Headphone amplifier output, can drive the general 3.5mm earphone
- High tone quality, low noise
- Power-off memory
- DC5V/1A power adapter
SPECIFICATIONS: ADSW0006M1
- Analog Audio Output Support audio format ........................ PCM/LPCM
- DAC sample frequency range.......................... 32～192 KHz
- DAC Bit rate range.................................16～24 Bit
- Digital input level................................0.1~1Volts p-p
- L/R output level(1kHz@0dB)........................................1V RMS
- Headphone output power (1kHz@0dB RL=32)......................30mW
- SNR @ 0dB(CCIR/ARM)................................90dB
- Distortion......................................0.1%
- Frequency response...............................20Hz~20KHz
- Max working current ...................................100mA
- Power adapter format Input ........................ AC 100V～240V 50HZ/60Hz, DC5V/1A
- Operating Temperature range ............................-10 to +55℃
- Storage Temperature range...........................-20 to +60℃
- Operating Humidity range .......................10 to 90%RH (No Condensation)
- Storage Humidity range........................5 to 95%RH (No Condensation)
- Case Dimension (L x W x H) ...........................85x62x21 (mm)
- Weight ..........................................130g
