product infomation

  • Item Name:
  • Factory:Hiyou
  • Origin:China
  • Time Left:299d 21h(0000-00-00 00:00:00)
  • Characteristic

    Large LCD for easy reading
    Full protection design against burn
    With temperature and frequency test function
    With double fuse, safe and reliable
    With PVC shockproof holster

    Technology features

    DCV: 2000m-20-200-600V                        ±0.5%
    ACV: 2000m-20-200-600V                                           ±1.0%
    DCA: 20u-20m-200m-10A                                            ±1.8%
    ACA: 20m-200m-10A                                                     ±2.0%
    Resistance: 200-2K-20K-200K-2M-20M-200MΩ      ±1.0%
    Capacitance: 2n-20n-200n-2u-20uF                           ±4.0%
    Frequency: 2K-20KHz                                                     ±3.0%
    Temperature: -20ºC~1000ºC                                        ±2.0%

    Description

    LCD size: 66x34mm
    Max display: 1999
    Low battery indication: yes
    Overload protection: yes
    Diode test: yes
    Continuity buzzer test: yes
    Transistor test: yes
    Auto power off: yes
    Data hold: yes
    Power supply: one 9V 6F22 battery
    Product size: 193x88x35mm
    Product weight: about 348g (with holster)
    Standard Accessories: meter (with battery), multi-function socket, holster, test lead, thermocouple, manual

Characteristic

Large LCD for easy reading
Full protection design against burn
With temperature and frequency test function
With double fuse, safe and reliable
With PVC shockproof holster

Technology features

DCV: 2000m-20-200-600V                        ±0.5%
ACV: 2000m-20-200-600V                                           ±1.0%
DCA: 20u-20m-200m-10A                                            ±1.8%
ACA: 20m-200m-10A                                                     ±2.0%
Resistance: 200-2K-20K-200K-2M-20M-200MΩ      ±1.0%
Capacitance: 2n-20n-200n-2u-20uF                           ±4.0%
Frequency: 2K-20KHz                                                     ±3.0%
Temperature: -20ºC~1000ºC                                        ±2.0%

Description

LCD size: 66x34mm
Max display: 1999
Low battery indication: yes
Overload protection: yes
Diode test: yes
Continuity buzzer test: yes
Transistor test: yes
Auto power off: yes
Data hold: yes
Power supply: one 9V 6F22 battery
Product size: 193x88x35mm
Product weight: about 348g (with holster)
Standard Accessories: meter (with battery), multi-function socket, holster, test lead, thermocouple, manual
